- High-Output Welding
- Delivers up to 600 amps of welding output for demanding industrial applications.
- Supports Stick, MIG, Flux-Cored, RMD®, Pulsed MIG, DC TIG, Submerged Arc, and Air Carbon Arc processes.
- Integrated Air Compressor
- Built-in Ingersoll Rand industrial rotary-screw compressor eliminates the need for a separate compressor.
- Delivers 40 CFM at idle and 60 CFM while running at 100 PSI, with a 100% duty cycle.
- Ideal for air carbon arc gouging and pneumatic tools.
- Powerful Auxiliary Power
- Provides up to 20,000 watts continuous / 27,000 watts peak three-phase power.
- Provides 12,000 watts continuous / 15,000 watts peak single-phase power for tools and jobsite equipment.
- Heavy-Duty Deutz Diesel Engine
- Powered by a 65.7 HP Deutz TD2.9 L4 turbocharged, four-cylinder diesel engine.
- EPA Tier 4 Final compliant with automatic glow plugs and a 120V block heater.
- Dynamic DIG™ Technology
- Provides ultra-adaptive arc control for smooth, consistent welding.
- Fine-tunes the arc to match the application, material, fit-up, and welding technique.
- ArcReach® Technology
- Adjust welding parameters at the feeder or remote without a control cord.
- Reduces trips back to the machine and keeps controls closer to the work area.
- Electronic Engine & Compressor Display
- Displays fuel level, engine hours, coolant temperature, oil pressure, RPM, air pressure, and compressor hours.
- Tracks maintenance intervals and diagnostics for quick and easy servicing.
- Independent Compressor Control
- Run the compressor only when compressed air is needed.
- Helps reduce fuel consumption and unnecessary compressor hours.
- Built for Welder Trucks
- Available in welder-truck-specific configurations with critical controls positioned for easier ground-level access.
- Built for demanding service and welding truck applications.
