STA 1000 Hybrid


  • Price : Contact us for price
  • Product Type : Hillsboro Flat Decks
  • Manufacturer : Hillsboro
  • Model : STA 1000
  • Year : 2024


    • 2 year limited warranty
    • Epoxy primer and polyurethane black paint
    • Headache rack with 1 ¼” square louvers and LED lights
    • 1/8” steel treadplate floor
    • 30K mounting plate with 2 5/16” ball & flush mount lid
    • Ready to accept Hillsboro B&W conversion kit / allows for use of B&W Companion
    • 5” structural channel long sills and 2 ½” crossmembers
    • Inboard stake pockets and 6” fold down sides with multiple tie locations
    • Sides have greaseable hinges, slam latch and rubber bump stop
    • Tapered rear with step
    • Tapered front on 96” wide dual wheel beds
    • Corrosion resistant
    • Supersize storage compartments
    • Toolboxes have weather-resistant
    • EPDM closed-cell foam seal
    • Toolboxes and skirting made of .125 thick aluminum
    • 18K rated 2 ½” receiver tube (2” adapter included)
    • Board holders across front and rear of bed
    • LED lights (6) stop turn & tail and (4) back-up
    • LED clearance & side marker lights
    • Dual tag lights
    • Sealed wiring harness with plug in connections
    • Factory installed filler neck mounting bracket with fuel fill knockout

    Customize it your way – see the optional add-on sliders below ⬇️

    The perfect balance of strength and durability.

    The BEST features of aluminum & steel truck beds COMBINED.

    This aluminum-skirted bed provides corrosion resistance in the areas most often impacted by rust and rot on a typical skirted bed, with toolboxes to provide convenient storage and protection for your equipment. With 5” structural channel long sills and 2 ½” cross members, you know you are driving a structure that is made for durability. Tow loads safely across town, the province, or the country — and look good doing it.

    Manufacturer Hillsboro
    Model STA 1000
    Year 2024
    Submit your review

    Create your own review

    Arrow Equipment
    Average rating:
     0 reviews


    Installing this deck takes on average about 7 hours.
    We have loaner truck that can be borrowed for the day.
    Yes, we can remount most backup cameras into the truck deck.
    These can sometimes be remounted but it must be completed at the truck dealership.
    Yes, all Hillsboro truck decks come standard with a 2 5/16th ball hitch.
    You can leave it at our shop if it isn’t needed, or it can be strapped down on top of the truck deck to be taken home. Just bring straps with you.
    We accept e-transfer, cheque, bank draft, or certified cheques. Credit cards on amounts over $1000 are subject to a 3% fee.
    Yes, we work with LeaseLine to get the best rates.
    Yes, if your box has been damaged and you have an SGI claim value, you can get a payout, then this can be used against your purchase.
